PHASE ONE iXG 100MP - 120MM CAMERA

Color Accuracy & Superior Detail

The iXG Camera System uses CMOS sensors in both the iXG 100MP and
iXG 50MP models to ensure the highest resolution and lowest noise levels.
These sensors produce the most accurate colors and minute details,
enabling accurate reproduction for all CH cultural heritage applications.

The degree of detail, quality and accuracy of color is crucial for the accurate
reproduction of precious books, artworks etc.
The iXG 100MP Achromatic model uses the all new Sony 100MP Achromatic sensor,
combining the highest possible resolution and class- leading wide spectrum sensitivity
that are so desired for specialized applications such as multi-spectral and NIR (Near Infra-Red) imaging.

Schneider Kreuznach Optics

The iXG Camera utilizes integrated Flat Field Optics with the
72mm and 120mm Schneider Kreuznach lenses.
This compatibility addresses the needs of at copy work,
particularly useful for libraries, archives, and universities, for example.
The Schneider Kreuznach lens design in combination with the digital lens
perfection of Capture One CH, offers the highest quality in terms of resolution,
atness, sharpness, distortion and color required for the most demanding
reproduction applications.

Teknisk data:

Imaging sensor - 100MP

Lens mount - Phase One iXG

Shutter type  -  Leaf shutter, intergrated in lens (reliance shutter/RS shutter)

Shutter speed  -  1/250s – 30s

Focus positions  -  Close range to near infinity, 23mm max. extension

Focus control  -  Motorized & encoded, controlled from software

Mechanical mounts  -  Threaded holes at top & bottom with a dedicated L-Bracket

Triggering options  -  Hand release, host capture from software

Flash Output  -  Via Secured LEMO connector

Live View / HDMI*  -  1920x1080 25p/30p, 1280 x 720 50p/60p

Data Storage  -  USB 3.0 Tethered to Capture One CH, PRO and DB

Dimensions (mm)  -  Focused to in nity: 150 x 120 x 100 Focused to close range: 180 x 120 x 100

Weight (g)  -  2300 (Including 72 mm lens and mounting bracket)

Operational temp range (c)  -  10-35 (o ce environment)

Humidity (%)  -  15-80 (o ce environment)

* Will be available at a later date.
